FC Model

Enbon FC अल्ट्रा पतला, कम बिजली खपत वाला, वाटरप्रूफ आउटडोर फिक्स्ड माउंट HD LED डिस्प्ले | Enbon LED डिस्प्ले निर्
  1. Lightweight Cabinet 8KG
  2. Special waterproof design : IP65
  3. Support front and back service
  4. Low power consumption
  5. Different modules use same HUB
IP65P2.604P3.91P2.974500nits185w/sqm

विवरण

उत्पाद विनिर्देश

Item Outdoor
Pixel Pitch 1.95 2.604 2.97 3.91
LED lamp SMD1415 SMD1415 SMD1415 SMD1921
Density(dots/m2) 262144 112896 112896 65536
Brightness ≥4500 nits ≥4500 nits ≥4500 nits ≥6000 nits
IP rating IP65 IP65 IP65 IP65
Cabinet Materiel Die-casting Aluminum
Scan 32scan 24scan 21scan 16scan
Module weight 1kg 1kg 1kg 1kg
Cabinet Weight 8kg 8kg 8kg 8kg
Module size(mm) 250*250 250*250 250*250 250*250
Cabinet size(mm) 500*500*85 500*500*85 500*500*85 500*500*85
Module pixel 128*128dots 96*96dots 84*84dots 64*64dots
Cabinet pixel 256*256dots 168*168dots 168*168dots 128*128dots
Max Power 550w/sqm 550w/sqm 550w/sqm 550w/sqm
Average Power 185w/sqm 185w/sqm 185w/sqm 185w/sqm
Viewing Angle Horizontal 140(+70/-70) deg               Vertical 140(+70/-70)deg
Control way synchronous/asynchronous
Gray Scale 16 bit
Operating system AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
Work humidity 10% ~ 90%
Work temperature  ﹣20 ~﹢65℃


LED Module

Pixel Pitch P1.95,P2.604,P2.97,P3.91
LED lamp SMD1415/1921
Brightness ≥4500nits
Module pixel 128*128/96*96/84*84/64*64dots
Cabinet pixel 256*256/168*168/128*128

Appearance

Module size 250*250mm
Cabinet size 500*500*85mm
Module weight 1kg
Cabinet Weight 8kg


Working Environment

Work humidity 10% ~ 90%
Work temperature ﹣20 ~﹢65℃


System parameter

Operating system AV, S-Video, VGA, DVI, YPbPr,
HDMI, SDI
Gray scale 16bit


Power

Max Power 550w/sqm
Average Power 185w/sqm


Waterproof grade

IP rating IP65

Control system

Control way Synchronous/Asynchronous
Viewing Angle H140(+70/-70) deg
V140(+70/-70)deg
Scan 32scan,24sacn,21scan,16scan

Material density

Density 262144/1128961/65536dots
Cabinet Materiel Die-casting Aluminum
